N-8410MS
Analog Standard Master Station
This Master Station is designed to connect to the N-8400RS Sub Station Interface Unit, and provides hands-free or handset conversation of high sound quality. This station can be mounted to the wall using an optional YC-280 wall mounting bracket.
- Paging and Communication function
- Hands-free or handset conversation
- High sound quality
- Status LED
- Specifications
- Application examples
- Equipment
- Tender text
- Downloads
Specifications
Specifications for product:
| N-8410MS | RS-450 | RS-460 | RS-470 | RS-480 | |
|---|---|---|---|---|---|
| Power source |
24 V DC (supplied from the sub station interface unit N-8400RS) |
||||
| Frequency response |
300 Hz - 7 kHz |
||||
| Control output |
Open collector output: 30 V DC, 30 mA |
||||
| Dimensions |
148 x 208 x 70.5 mm (W x H x D) |
120 x 120 x 41.5 mm (W x H x D) |
120 x 120 x 49.5 mm (W x H x D) |
120 x 120 x 49.5 mm (W x H x D) |
120 x 120 x 50.5 mm (W x H x D) |
| Finish |
ABS resin, grey |
Stainless steel |
Stainless steel |
Stainless steel |
Stainless steel |
| Weight |
0.72 kg |
0.51 kg |
0.54 kg |
0.55 kg |
0.58 kg |
| Operating temperature |
0 °C to +40 °C |
0 °C to +40 °C |
0 °C to +40 °C |
0 °C to +40 °C |
