N-8000EX
IP Network Intercom Exchange
The IP Intercom Exchange uses packet audio technology to permit connection of up to sixteen N-8000 Series stations, and features two outputs for public address paging. Hands-free conversation is possible between stations. Moreover, the exchange is equipped with a networking interface, allowing up to 192 exchanges to be connected over a network using additional IP intercom exchanges. The Exchange can be mounted in an EIA standard rack (1-unit size) or to a wall using the supplied bracket.
- 10 Base-T / 100 Base-TX Ethernet network connection
- 16 station capacity
- Stations connect to exchange via twisted pair cable
- 4 internal / 8 external speech links
- 2 audio paging outputs, 2 relay outputs
- Specifications
- Application examples
- Tender text
- Downloads
Specifications
Specifications for product:
| N-8000EX | N-8010EX | |
|---|---|---|
| Network |
10BASE-T/100BASE-TX (Automatic-Negotiation) |
10BASE-T/100BASE-TX (Automatic-Negotiation) |
| Network protocol |
TCP/IP, UDP, ARP, ICMP, HTTP, RTP, IGMP |
TCP/IP, UDP, ARP, ICMP, HTTP, RTP, IGMP |
| Audio transmission system |
Unicast, Multicast |
Unicast, Multicast |
| Voice packet loss recovery |
silence insertion |
silence insertion |
| Audio delay time |
80 ms, 320 ms (controllable on the software) |
80 ms, 320 ms (controllable on the software) |
| Applicable model |
N-8050DS, N-8031MS, N-8000MS, N-8010MS, N-8011MS, N-8033MS, N-8065MS Q-TEE, N-8020MS, N-8050SB, N-8050SB |
N-8050DS, N-8031MS, N-8000MS, N-8010MS, N-8011MS, N-8033MS, N-8065MS Q-TEE, N-8020MS, N-8050SB, N-8050SB |
| Power source |
220 - 240 V AC, 50 / 60 Hz |
220 - 240 V AC, 50 / 60 Hz |
| Power / current consumption |
50 W (at rated), 75 W (max.) |
50 W (at rated), 75 W (max.) |
| Speech link |
Internal: 4 / External: 8 |
Internal: 1 / External: 2 |
| Line capacity |
16 |
16 |
| Wiring method |
1 set of twisted pair cable |
1 set of twisted pair cable |
| Transmission range |
Max. 1500 m (ø 0.65 mm, Loop resistance < 170 Ω) / 2,900 m (ø 0.9 mm) |
Max. 1500 m (ø 0.65 mm, Loop resistance < 170 Ω) / 2,900 m (ø 0.9 mm) |
| Paging output |
Audio: 2 channels max. 0 dBV, 600 Ω, balanced, detachable terminal block |
Station paging only |
| Operating temperature. |
0 °C to +40 °C |
0 °C to +40 °C |
| Operating humidity. |
90 % RH or less (no condensation) |
90 % RH or less (no condensation) |
| Dimensions. |
420 x 44.3 x 356 mm (W x H x D) |
420 x 44.3 x 356 mm (W x H x D) |
| Finish. |
Steel plate, pre-coated, 30 % gloss, black |
Steel plate, pre-coated, 30 % gloss, black |
| Accessory (included) |
AC power cord (2 m) x 1, CD (for PC setting, maintenance use) x 1, Removable terminal plug (4 pins) x 2, Mini-clamp plug (2 pins) x 20, Plastic foot x 4, Screw for fitting plastic foot x 4, Rack mounting bracket x 2, Screw for rack mounting x 4, Wall mounting bracket x 2, Screw for mounting bracket x 8, Screw for wall mounting x 4 |
AC power cord (2 m) x 1, CD (for PC setting, maintenance use) x 1, Mini-clamp plug (2 pins) x 20, Plastic foot x 4, Screw for fitting plastic foot x 4, Rack mounting bracket x 2, Screw for rack mounting x 4, Wall mounting bracket x 2, Screw for mounting bracket x 8, Screw for wall mounting x 4 |
