WM-5225 H01

Wireless microphone

The WM-5225 Wireless Microphone employs an electret condenser microphone capsule and is suitable for any applications. Thanks to the PLL-synthesizer system, 64 different operating frequencies are made available. A high output power ensures stable radio signal transmission.

  • Condenser microphone with high quality electret condenser capsule, high sensitivity and excellent sound quality
  • Slim, extremely lightweight and can be held comfortably and securely
  • Comes with an indispensable on/off switch, which at the same time acts as a rolling stopper
  • With a maximum SPL of 126 dBSPL it is the right choice for even the most energetic speaker




  • Specifications
  • Application examples
  • Equipment
  • Tender text
  • Downloads
Specifications
Specifications for product:
WM-5225 H01 WM-5265 H01 WM-5270 H01
Power source

Battery 1 AA size alkaline battery, 1.5 V or WB-2000-2

Battery 1 AA size alkaline battery, 1.5 V or WB-2000-2

Battery 1 AA size alkaline battery, 1.5 V

Battery life

10 h

10 h

10 h

Microphone type.

Electret condenser

Dynamic

Dynamic

Directivity

Cardioid

Hypercardioid

Cardioid

Frequency range

578 – 606 MHz

578 – 606 MHz

578 – 606 MHz

Selectable frequencies

64

64

64

Simultaneous channels

16

16

16

AF response

100 Hz - 15 kHz

100 Hz - 15 kHz

80 Hz - 15 kHz

RF output power

10 mW

10 mW

10 mW

Max. input level (value)

126 dBSPL

132 dBSPL

142 dBSPL

Max. input level

126 dBSPL

132 dBSPL

142 dBSPL

Operating temperature.

-10°C ... +50°C

-10°C ... +50°C

-10°C ... +50°C

Operating humidity.

30% - 85%

30% - 85%

30% - 85%

Dimensions.

43.6 x 231.5 mm (Ø x D)

50 x 229 mm (Ø x D)

48 x 244 mm (Ø x D)

Finish.

Resin, black

Resin, black

Metal, dark grey

Accessory (included)

Microphone holder (with stand adapter) x 1, storage case x1, screwdriver (for setting) x1

Microphone holder (with stand adapter) x 1, storage case x1, screwdriver (for setting) x1

Microphone holder (with stand adapter) x1, storage case x 1, screwdriver for setting (housed in the body) x1, rolling stopper x1
