TS-907
Infrared Transceiver
The TS-907 Infrared Transmitter/Receiver of the Infrared Conference system is designed for high ceiling applications. Since the system is cordless, it can be easily installed and removed. Communications between the TS-907 and conference units are performed by means of infrared signals and the TS-907 permits transmit and receive with the Central unit. It can be mounted not only to the ceiling and wall but on the microphone stand.
- Cordless, easy to install and remove
- Communication between units performed by means of infrared signals
- Variety of mounting methods: ceiling, wall and microphone stand
- Designed for high ceiling applications
- Specifications
- Equipment
- Tender text
- Downloads
Specifications
Specifications for product:
| TS-907 | TS-905 | |
|---|---|---|
| Power source |
24 V DC supplied from the central unit |
24 V DC supplied from the central unit |
| Current consumption (value) |
180 mA |
150 mA |
| Connection |
BNC jack |
BNC jack |
| Current consumption |
180 mA |
150 mA |
| Dimensions. |
120 x 71.3 mm (Ø x H) |
120 x 71.3 mm (Ø x H) |
| Finish. |
ABS resin, black |
ABS resin, black |
| Accessory (included) |
Mounting bracket x 1, stand mounting bracket x1, stand mounting bracket attaching screw x3, thread Adapter (U5/16 - NS5/8) x 1 |
Mounting bracket x 1, stand mounting bracket x1, stand mounting bracket attaching screw x3 |
