RS-142
Switch Panel - PCB
The RS-142 is a switch board designed for use with the N-8000RS or N-8010RS 2-Core Shielded Substation Interface Unit. You can make desired switch panels to meet intended purposes by combining the RS-142 with the separately prepared operation panel having 2 switches to be used as call buttons. Also, it can be used in connection with the RS-141 Ip Intercom Option Handset.
- Possibility to make desired switch panels to meet intended purposes by combining RS-142 with the separately prepared operation panel
- 2 switches to be used as call buttons
- Half-duplex conversation
- Conversation via external speaker (optional)
- Handset conversation (with optional RS-141)
- Specifications
- Application examples
- Equipment
- Downloads
Specifications
Specifications for product:
| RS-142 | RS-442 | |
|---|---|---|
| Rated input (100 V) |
1 W 1 W |
|
| Control output |
Open collector, maximum controlled voltage: 30 V DC Control current: 30 mA |
|
| Finish |
Stainless steel |
|
| Weight |
30 g |
0.14 kg |
| Operating temperature |
0 °C to +40 °C |
Application examples
Equipment
Downloads
