DISCONTINUED
M-01F
Microphone Input Module
The M-01F is a microphone input module to be used in conjunction with the 900 series components and other TOA's equipment. It has a transformer balanced microphone input with female XLR type connector, phantom power supply function, and gain and tone controls.
- Phantom power
- Balanced, low impedance
- Filter: High pass, low pass
- Connector: XLR
- Specifications
- Equipment
- Tender text
- Downloads
Specifications
Specifications for product:
| M-01F | |
|---|---|
| Finish |
Steel plate |
| Dimensions |
35 x 78 x 88 mm (W x H x D) |
| Weight |
110 g |
| Power source |
Supplied from VX-2000 |
| Current consumption (value) |
9 mA |
| Input impedance |
600 Ω, balanced |
| Connectable microphones |
1 |
| Input sensitivity |
-70 ~ -50 dBu |
| Current consumption |
9 mA |
